nylon 12mm reset switch one normally open dot led illuminated pushbutton
▶Product Description:
Our Nylon 12mm reset button is the perfect solution for any application that requires a high-quality switch. With a 12mm mounting hole and a switch length of approximately 22mm, our reset button is easy to install and can be used in a variety of applications, including gamepads, remote sensing handles, motorcycles, and other equipment.
The button features a domed head dot LED and is available in a range of colorful head colors, making it a great choice for applications where visual appeal is important. The 1NO switch contacts provide reliable performance, while the 4 pins terminal design allows for easy wiring and connection to a variety of devices.
Our Nylon 12mm reset button is also waterproof, with an IP67 rating, ensuring reliable performance in wet and damp environments. Additionally, our buttons support custom symbol logos, allowing you to personalize your equipment.
Overall, our Nylon 12mm reset button offers excellent durability, reliability, and performance, making it an ideal choice for any application where high-quality switches are required. Contact us today to learn more about our products and to place your order.
▶Product Model Specification:
▶Product Size:
▶Technical Parameter:
|
HBDGQ Series domed head nylon 12mm reset switch |
|
| Product model : | HBDGQ12B-□D/J/PA |
| Mounting hole size : | 12mm |
| Switch value: | Ith:3A,UI:250V |
| Operation type: | Momentary,Latching |
| Contact configuration: | 1NO |
| Appearance material: | Head: Nylon; Switch button shell: Nylon; Pedestal: PBT; |
| Terminal type: | Pin terminal |
| Working environment temperature: | -25℃～+65℃ |
| Movement stroke: | About 2.5mm |
| Connection form: | Supporting connector/Welding wire |
| Head color: | Red/Green/Yellow/Blue/White/Black |
| Protection grade: | IP67 |
| Insulation resistance: | ≥100MΩ |
| Electrical resistance: | AC2500V, 1min, No flicker and breakdown |
▶Problems Encountered By Buyers:
Q:Does the switch have any special certifications, such as UL, CE, or RoHS?
A: “Our HBD series buttons and HBD series indicator light are certified with the CE certificate. The UL certificate covers our HBDS1 series buttons, HBDGQ series buttons, and HBDS1-AWY series buttons.Our HBD series buttons are certified with the Rohs certificate. Since this button is an HBDGQ series button switch, it has all of these certificates.”
Q:Can the switch be used in a high-vibration environment, such as on a vehicle or industrial machine?
A: “Our metal button is housed in a destruction-resistant material that is capable of withstanding high vibration environments. It is often used in industrial machines or lawn mowers, making it suitable for use in vehicles or industrial machinery without any concerns.”
Q:What is the lead time for ordering and receiving the 12mm reset switch?
A: “After payment is received for your order, we generally require 3-5 days to process and ship it. If you choose fast logistics, you can expect delivery in about 10 days. For larger orders, delivery may take around 20-30 days.”
Thank you for your trust and support!
* Founded in 2003 and experienced in the field of pushbutton switches for more than 20 years.
* We have a complete production line, advanced production equipment, experimental equipment and testing instruments, in strict accordance with the requirements of IS09001 quality assurance system.
* And the world’s top 500 enterprises have cooperation.
* Main production buttons: Anti-vandal metal push button switches(which are waterproof), plastic push button switches, high current switches for equipment control and panel mounting, micro travel switches(which can be used in elevator),touch switch ,20a high current switch, signal lamp(indicator), buzzers and push button accessories.
* Large quantity can enjoy a certain discount.
*Where can our push button switches be used?Control box,elevator,moving train,industrial lathe machine,New energy machine Charging pile,ice cream machine,blender,Coffee machine,control panel,motorcycle,Cutting Machine,Machine tool equipment,Medicalequipment,automation equipment,solar equipment,yacht,security check equipment,heating equipment,CNC equipment,control handles,Audio equipment,diy panel.,etc
