RGB momentary push button 22mm one normally open and one normally close ring led switches
▶Product Description:
New product 22mm 10 amp high current ring led switch with connect.Support Tri-color light, waterproof up to IP65, purchase button can be equipped with connector without additional payment.A variety of head type selection, commonly used in medical equipment, control machines, CNC equipment.
▶Product Model Specification:
▶Product Size:
▶Technical Parameter:
|
HBDS1-D22C Metal series flat head ring LED switch |
|
| Product model : | HBDS1-D22C-□E(Z)/J/S |
| Mounting hole size : | 22mm |
| Switch value: | Ith:5A(10A),UI:250V |
| Operation type: | Momentary,Latching |
| Contact configuration: | 1NO1NC |
| Appearance material: | Head: Stainless steel; Switch button surface: Stainless steel; Base: Plastic PA66; Contact: Silver alloy; |
| Terminal type: | Pin terminal |
| Working environment temperature: | -25℃～+65℃ |
| Connection form: | Supporting connector/Welding wire; |
| Lamp bead parameters | |
| Rated voltage : | 6V/12V/24V/36V/110V/220V;(Other voltages can be customized) |
| Rated current: | ≤20mA |
| Led color: | Red/Green/Yellow/Orange/Blue/White/RG/RB/RGB |
| Led life: | 50000 hours |
| Protection grade: | IP67 |
▶Problems Encountered By Buyers:
Q:Whether there is 15A large current button switch?
A:“Emmm,Our buttons support a maximum current of 20A, but they are relatively similar to la38 series buttons and Lay5 series buttons.”
Q: Can you make waterproof IP67 metal button RGB?
A:“Yes, we can do. You can contact us by email for more information.”
Q:Can you make RGW tri-color button?
A:“This needs decided according to our actual warehouse materials.”
Thank you for your trust and support!
* Founded in 2003 and experienced in the field of pushbutton switches for more than 20 years.
* We have a complete production line, advanced production equipment, experimental equipment and testing instruments, in strict accordance with the requirements of IS09001 quality assurance system.
* And the world’s top 500 enterprises have cooperation.
* Main production buttons: Anti-vandal metal push button switches(which are waterproof), plastic push button switches, high current switches for equipment control and panel mounting, micro travel switches(which can be used in elevator),touch switch ,20a high current switch, signal lamp(indicator), buzzers and push button accessories.
* Large quantity can enjoy a certain discount.
*Where can our push button switches be used?Control box,elevator,moving train,industrial lathe machine,New energy machine Charging pile,ice cream machine,blender,Coffee machine,control panel,motorcycle,Cutting Machine,Machine tool equipment,Medicalequipment,automation equipment,solar equipment,yacht,security check equipment,heating equipment,CNC equipment,control handles,Audio equipment,diy panel.,etc
Our buttons are widely used, directly sold by manufacturers, more assured of quality, and have sufficient product inventory for you to choose. One-to-one sales, if you have any dissatisfaction, you can complain
* Pay attention to our official social media, send subscribed pictures, you can enjoy discounts and some products 10% off discount!!!
We will conduct live product explanation every Tuesday or Thursday from time to time. If you have any questions about the product, you can watch our live broadcast to learn more~Welcome new and old customers to watch!
The latest live broadcast will start at 4 p.m on August 11th(China time)
Thank you for your support!
