push button switch normally open 16MM ring led 12v light on off
▶Product Description:
Waterproof ip65 ring-shaped button with light, normally open switch contact, screw foot terminal method, tight wiring thread, support for a variety of color lamp beads selection, 12v, 24v common lighting voltage value. Often used in filters, water dispensers, CNC machinery, medical devices and other equipment.
▶Product Model Specification:
▶Product Size:
▶Technical Parameter:
|
HBDGQ16F-10 Series screw terminal 16mm ring led switch |
|
| Product model : | HBDGQ16F-10/L/S |
| Mounting hole size : | 16mm |
| Head type: | Flat head |
| Switch value: | Ith: 3A,UI: 250V |
| Operation type: | Momentary |
| Contact configuration: | 1NO |
| Appearance material: | Head: Stainless steel; Switch button surface: Stainless steel; Pedestal: PBT; |
| Terminal type: | Pin terminal |
| Working environment temperature: | -25℃～+65℃ |
| Movement stroke: | About 0.5mm |
| Connection form: | Welding wire |
| Protection grade: | IP65 |
| Contact resistance: | ≤50mΩ |
| Insulation resistance: | ≥100MΩ |
| Electrical resistance: | AC250V, 1min, no flicker and breakdown |
| Life | |
| Electrical part: Operate 50,000 times under rated load without any abnormality | |
| Mechanical part: No abnormal movement for 1000,000 times | |
▶Problems Encountered By Buyers:
Q: Can it be plated in black?
A:“Yes,there is no problem, most of the customers have bought this type of black plated with leads from us.”
Q: Will this work as a push start button on truck or car?
A: “It's only a 3 amp switch and the starter relay might take more than 3 amps with bigger starters.”
Q: Does this button type have a pin terminal type?
A: “16mm lighted momentary normally open button switch, we have pin terminal and screw terminal.”
