22mm Plastic Illuminated Switch SPDT Momentary push button Waterproof 1NO1NC by china Supplier and Factory
▶Product Description:
Introducing the versatile 22mm Plastic Illuminated Switch, designed to meet the demands of a wide range of applications. This SPDT momentary switch features a waterproof 1NO1NC design, making it a reliable choice for various industries and use cases. Manufactured by leading industry experts, this high-quality switch is both durable and functional.Ideal for applications such as industrial control panels, automotive dashboards, marine equipment, home automation systems, outdoor installations, and safety-critical scenarios, this 22mm illuminated switch offers versatility and reliability. Its waterproof design ensures consistent performance, even in challenging environments exposed to moisture or dust.Choose the 22mm Plastic Illuminated Switch for a dependable and adaptable switching solution, crafted by top manufacturers, suppliers, and factories in the industry. Enhance your projects with this high-performance switch that caters to a diverse range of requirements and settings.
▶Product Model Specification:
▶Product Size:
▶Technical Parameter:
|
HBDGQ Series power plastic push buttons |
|
| Product model : | HBDGQ22F-□(Z)/J/S |
| Mounting hole size : | 22mm |
| Switch value: | Ith:5A,UI:250V |
| Operation type: | Momentary,Latching |
| Contact configuration: | 1NO1NC |
| Appearance material: | Head: PC; Switch button surface: PC; Pedestal: PBT; Contact:Silver alloy; |
| Terminal type: | Pin terminal |
| Working environment temperature: | -25℃～+65℃ |
| Movement stroke: | About 2.8mm |
| Connection form: | Supporting connector/Welding wire |
| Protection grade: | IP65 |
| Contact resistance: | ≤50mΩ |
| Insulation resistance: | ≥100MΩ |
| Electrical resistance: | AC2500V, 1min, no flicker and breakdown |
| Life | |
| Electrical part: Operate 50,000 times under rated load without any abnormality | |
| Mechanical part: No abnormal movement for 1000,000 times | |
▶Problems Encountered By Buyers:
Q: Are there any other light colors or light patterns available for the illuminated switch?
A:“This lighting switch, there are also ring, ring power symbol type head options, you can also customize the head symbol to make you want to pattern type.”
Q: Are there any other switch configurations or contact types available, such as DPDT switches?
A:“This nylon material type push-button switch does not support DPDT at present. If you do not consider the material problem, our other metal style series can meet it.”
Q: Are there any accessories or complementary products available, such as protective covers or mounting brackets?
A:“We have the capability to produce custom protective covers and connectors to suit your specific needs.”
