normally open push button mushroom head green 22 mounting holes 1no1nc switches for Industrial machine
▶Product Description:
Elevate your control systems with our 22mm normally open push button switch. Crafted to perfection, this switch is the epitome of precision and reliability. It boasts a 5A/250V rating, ensuring it can handle the demands of industrial operations. With an IP65 waterproof rating, it's built to withstand challenging environments.
Your Custom Control
Featuring 1NO contact type and screw terminals, installation is a breeze. The switch's head, in a distinctive mushroom shape, offers an ergonomic and intuitive interface. Whether you require a momentary or latching operation, this switch is versatile enough to meet your needs.
Color LED illuminated
Customize your control panel with ease. The LED indicator, available in red, green, and blue, not only adds a pop of color but also provides clear feedback on your system's status.
Reliable Precision
When it comes to control, precision is non-negotiable. Our normally open push button switch promises accuracy, ensuring your operations run smoothly, efficiently, and with unwavering control.
Upgrade your control systems with a switch that offers the perfect blend of functionality and durability. With our normally open push button switch, you're not just investing in a device; you're investing in precision control. Make it yours today.
▶Product Model Specification:
▶Product Size:
▶Technical Parameter:
|
red head mushroom head normally open push button |
|
| Product model： | HBDY5-KA-□MD/R |
| Mounting hole size : | 22mm |
| Switch value: | Ith:10A,UI:600V |
| Operation type: | Momentary,Latching |
| Contact configuration: | 1NO,1NC,1NO1NC,2NO2NC |
| Appearance material: | Head:PA66; Switch button surface:PC; Contact:Silver alloy; |
| Terminal type: | Screw terminal |
| Connection form: | With wire; |
| Lamp bead parameters | |
| Rated voltage : | 6V/12V/24V/36V;110V/220V;(Other voltages can be customized) |
| Rated current: | ≤20mA |
| Led color: | Red/Green/yellow/orange/blue/white |
| Protection grade: | IP65 |
* Founded in 2003 and experienced in the field of pushbutton switches for more than 20 years.
* We have a complete production line, advanced production equipment, experimental equipment and testing instruments, in strict accordance with the requirements of IS09001 quality assurance system.
* And the world’s top 500 enterprises have cooperation.
* Main production buttons: Anti-vandal metal push button switches(which are waterproof), plastic push button switches, high current switches for equipment control and panel mounting, micro travel switches(which can be used in elevator),touch switch ,20a high current switch, signal lamp(indicator), buzzers and push button accessories.
* Large quantity can enjoy a certain discount.
*Where can our push button switches be used?Control box,elevator,moving train,industrial lathe machine,New energy machine Charging pile,ice cream machine,blender,Coffee machine,control panel,motorcycle,Cutting Machine,Machine tool equipment,Medicalequipment,automation equipment,solar equipment,yacht,security check equipment,heating equipment,CNC equipment,control handles,Audio equipment,diy panel.,etc
